PCB Manufacturing

Design Guidelines

Printed circuit board design is one of the most critical aspects for the success of any electronic assembly within a product. It requires specialist skills, knowledge of PCB design software, and various standards and techniques.

Circuit Board Materials

Material selection and integration is an essential facet of Printed Circuit Board fabrication. With our extensive expertise with standard & advanced material types and related combinations, we offer a cost-effective solution for almost any design requirement. From high signal integrity to superior dimensional stability, trust Network PCB to make the optimal recommendation for every packaging requirement.

Material TypePartnersTypical Products
FR4/FR4 HIGH TGISOLA, TAIWAIN, VENTEC,IT180,185HR,370HR,VT42,VT47
Special FR4ISOLAIS410, FR408HR
RF/ HIGH FREQUENCY MATERIALROGERRO4003, RO4350, RO4360, RO4835
PTFE/ HIGH FREQUENCY/ CERAMIC BASEROGERRO3003, RO3006, RO3010, RO3210, RO5880, RO6002, RO6006, RO3010, RO6035
POLYIMIDEISOLA, ARLONG200, 85N
NELCONELCON4000, N4350, N5000
BLACK FR4VENTECVT42-B
MEGTRONPANASONICMEG6
FLEX COREDUPOINT, APEXYLAP SERIES
FLEX ADHESIVEDUPOINT, APEXYLLF/FR SERIES
FLEX COVERLAYDUPOINT, APEXYLLF/FR SERIES
